DISTRIBUTOR,PRO BILLET,CHEVY V-8,MARINE

Brand New MSD Pro-Billet Marine Certified Distributor, Red, Compatible with Chevy V8 Engines (Holley Part #8560).

Marine environments place rigorous demands on every component of the ignition system, especially the distributor. The combination of water spray, salt exposure, full throttle acceleration and harsh vibrations all take their toll.

The MSD Pro-Billet Distributor is the strongest and most accurate distributor you can put in your boat. The housing is CNC-machined from a billet of 6061-T6 aluminum creating a housing with no porosity. Internally, a QPQ coated shaft is guided by a sealed ball bearing and an extra long sintered bushing for highspeed stability.

Each distributor uses MSD's race-proven magnetic pickup to trigger the ignition control. Mounted just above the pickup is a mechanical advance assembly that is easy to adjust so you can dial-in an ignition curve to match your boat's application (except PN 8366).

For marine use, the distributor cap is bolted to the aluminum base. There are two flame arrestor holes with brass screens machined into the base of the distributor to prevent ignition of gas fumes that may build up in the engine compartment. A special Weathertight Connector is supplied to provide a positive-lock and water resistant connection.

NOTE: Only compatible with an MSD Series ignition.

Features:

• Must be used with an MSD Ignition Control
• Polished steel shaft is QPQ coated and guided by a sealed ball bearing for smooth operation at all rpms
• Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
• CNC machined billet aluminum housing and billet aluminum base providing superior strength and great looks
• Rotor plate are fine blanked from chrome moly steel and QPQ coated for friction reduction
• Weight pins are staked and tig welded to the plate
• Locked-out mechanical advance

Specs:

• Brand: MSD
• Color: Red
• Distributor Type: Magnetic Pickup
• Product Type: Distributor

You can view and download the complete assembly instruction booklet here.
